AGV 22 - BIDIRECTIONAL WAFER KNIFE GATE VALVE

DESCRIPTION

  • Bidirectional wafer-design knife gate valve.
  • “Monoblock” onepiece cast iron body.
  • Stainless steel gate. Two rubber sleeves.
  • Provides high flow rates with low pressure drop.
  • Various seat materials available.
  • Face-to-face dimension in accordance with AAP Techniks standard.

GENERAL APLICATIONS

This knife gate valve is suitable for working in the mining industry, in loaded fluid transport lines, such as: water with stones, sludge, etc. and in general it is used for abrasive fluids in the chemical industry and waste water. Designed for the following applications:


Designed for the following applications :

  • Mining
  • Sewage treatment
  • Thermal power stations
  • Chemical plants
  • Energy Sector

SIZES

DN50 to DN1500

WORKING PRESSURE (∆P)

  • DN50 - DN 150 = 16 bar
  • DN200 - DN 600 = 10 bar
  • DN700 - DN 900 = 8 bar
  • DN1000 - DN 1200 = 6 bar

FLANGE DRILL HOLE

PN10 & ANSI B16.5 (150 LB)

OTHER COMMON FLANGES

  • PN 6, PN 16, PN 25, JIS standard
  • Australian standard, British standard.

QUALITY DOSSIER

All valves are tested hydrostatically at AAP Techniks, and material and test certificates can be provided.

  • Body test = working pressure x 1,5
  • Seat test = working pressure x 1,1
